Nascent Pipe & Tubes is a well-known firm that manufactures and distFlangesutes a wide range of SS 321 / 321H Screws, which is an electric-furnace processed austenitic stainless steel. These Stainless Steel 321 Screws is a titanium-stabilised version and used in particular applications within the sensitizing temperature range.
This titanium addition in Stainless Steel 321H Screws reduces or prevents carbide precipitation during welding and in the 800 ° – 1500 ° F service conditions. However local depletion within the weld area of Stainless Steel 321 Hex Head Screws can still be a problem leading to some inter-granular corrosion if later exposed to severe corrosive conditions.
Stainless Steel 321/321H Screw Manufacturers, Stainless Steel 321/321H Screw Suppliers, Stainless Steel 321/321H Screw Stockists, Stainless Steel 321/321H Screw Exporters
Stainless Steel 321/321H Screw Manufacturers in India, Stainless Steel 321/321H Screw Suppliers in India, Stainless Steel 321/321H Screw Stockists in India, Stainless Steel 321/321H Screw Exporters in India
The key property of Stainless Steel 321H Socket Head Cap Screws is the added titanium content stabilising the material and making its resistance to carbide precipitation when exposed to high temperatures and resistance to oxidation its main characteristics. Resistance to organic acids and some inorganic acids in Stainless Steel 321 Socket Set Screws is excellent. Stabilization in Stainless Steel 321H Anchore Screws is recommended for most severe service conditions (above 425 ° C) and particularly for material annealed at the upper side of the annealing temperature range.
Stainless Steel 321/321H Screw Manufacturers In Mumbai, Stainless Steel 321/321H Screw Suppliers In Mumbai, Stainless Steel 321/321H Screw Stockists In Mumbai, Stainless Steel 321/321H Screw Exporters In Mumbai
Stainless Steel 321 Blind Rivet Screws has excellent resistance oxidation to 1500 ° F (816 ° C) and good low temperature toughness. Stainless Steel 321H Concrete Screws has working temperatures of 2100 – 2300 ° F (1149 – 1260 ° C) are recommended for forging, upsetting and other hot working processes.
SS 321/321H Screws Specifications
| Specifications |
ASTM A 193 ASME SA 193 |
| Standard |
DIN, ASTM, BS and all International Standards |
| Length |
3 mm to 200 mm |
| Size |
M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Type |
Hex Head Screw, Socket Head Cap Screw, Socket Set Screws, Anchor Screw, Blind Rivet, Concrete screw, Threaded Screw, Steel Shoulder Screw, Panel Screw, Machine Screw. |
321/321H Stainless Steel Screws Chemical Composition
| Grade |
C |
Mn |
Si |
P |
S |
Cr |
N |
Ni |
Ti |
| SS 321 |
0.08 max |
2.0 max |
1.0 max |
0.045 max |
0.030 max |
17.00 – 19.00 |
0.10 max |
9.00 – 12.00 |
5(C+N) – 0.70 max |
| SS 321H |
0.08 max |
2.0 max |
1.0 max |
0.045 max |
0.030 max |
17.00 – 19.00 |
0.10 max |
9.00 – 12.00 |
4(C+N) – 0.70 max |
Stainless Steel 321/321H Screw Mechanical Properties
| Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| 8.0 g/cm3 |
1457 °C (2650 °F) |
Psi – 75000 , MPa – 515 |
Psi – 30000 , MPa – 205 |
35 % |
Equivalent Grades for 321/321H Stainless Steel Screw
| STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
EN |
| SS 321 |
1.4541 |
S32100 |
SUS 321 |
X6CrNiTi18-10 |
| SS 321H |
1.4878 |
S32109 |
SUS 321H |
X12CrNiTi18-9 |
