Nascent Pipe & Tubes is one of the prominent traders and stockiest for Stainless Steel 316 / 316L Fasteners (Screws), which would make the grain boundary areas less corrosion resistant. Stainless Steel 316 Hex Head Screws will be less susceptible to sensitization, a condition caused when carbon combines with chromium around the grain boundaries, thereby depleting the grain boundary areas of chromium.
Sensitization occurs with heating into the 800 Degree F to 1300 Degree F region, so Stainless Steel 316L Socket Head Cap Screws is a welding or annealing problem. If you use a Stainless Steel 316 Socket Set Screws with high carbon content the welds may crack spontaneously as they cool down from the welding, where this type of cracking is known as “hot brittleness”. In other words, Stainless Steel 316L Anchore Screws is more resistant to intergranular corrosion.
Stainless Steel 316 / 316L Screw Manufacturers, Stainless Steel 316 / 316L Screw Suppliers, Stainless Steel 316 / 316L Screw Stockists, Stainless Steel 316 / 316L Screw Exporters
Stainless Steel 316 / 316L Screw Manufacturers in India, Stainless Steel 316 / 316L Screw Suppliers in India, Stainless Steel 316 / 316L Screw Stockists in India, Stainless Steel 316 / 316L Screw Exporters in India
However, this is only an issue if Stainless Steel 316 Blind Rivet Screws needs to be welded over a period of several minutes or it’s heated to temperatures between the ranges 425 Degree C – 815 Degree C. Overall, Stainless Steel 316L Concrete Screws are highly durable, corrosion resistant, and perform well under high stress conditions.
Stainless Steel 316 / 316L Screw Manufacturers In Mumbai, Stainless Steel 316 / 316L Screw Suppliers In Mumbai, Stainless Steel 316 / 316L Screw Stockists In Mumbai, Stainless Steel 316 / 316L Screw Exporters In Mumbai
If you’re looking for a cheaper material, Stainless Steel 316 Threaded Screws are physically similar to the 316s (slightly less durable) but cost a little less. If you’re looking for highest durability, Stainless Steel 316L Steel Shoulder Screws have a higher molybdenum content, which increases their overall corrosion resistance.
SS 316-316L Screws Specifications
| Specifications |
ASTM A 193 ASME SA 193 |
| Standard |
IS, ASTM, BS and all International Standards |
| Length |
3 mm to 200 mm |
| Size |
M3 – M33 |
| Type |
Hex Head Screw, Socket Head Cap Screw, Socket Set Screws, Anchor Screw, Blind Rivet, Concrete screw, Threaded Screw, Steel Shoulder Screw, Panel Screw, Machine Screw. |
316 – 316L Stainless Steel Screw Chemical Composition
| Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
| 316 – 316L |
min. |
- |
– |
– |
– |
– |
16.0 |
2.0 |
10.0 |
- |
| max. |
0.08 |
2.0 |
0.75 |
0.045 |
0.03 |
18.0 |
3.0 |
14.0 |
0.10 |
Stainless Steel 316 – 316L Screw Mechanical Properties
| Grade |
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness |
| Rockwell B (HR B) max |
Brinell (HB) max |
| 316 – 316L |
515 |
205 |
40 |
95 |
217 |
Stainless Steel 316 – 316L Screw Physical Properties
| Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion (m/m/0C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-1000C (J/kg.K)Electrical Resistivity (n.m) |
Electrical Resistivity (n.m) |
| 0-1000C |
0-3150C |
0-5380C |
at 1000C |
at 5000C |
| 316 – 316L |
8000 |
193 |
15.9 |
16.2 |
17.5 |
16.3 |
21.5 |
500 |
740 |
