Nascent Pipe & Tubes is one of the prominent manufacturer and supplier of quality Monel Alloy 400 Fasteners (Bolts / Nuts), which is a solid solution alloy and can only be hardened by cold working. Monel Alloy 400 Hex Head Bolts are often required in complex applications, where corrosion and thermal resistance are demanded. Monel Alloy 400 Hex Head Nuts is majorly made up of Nickel and Copper, which also contain Iron with a small amount of manganese.
Monel Alloy 400 Square Bolts are very useful materials for the manufacture of high quality tubing products. One of the key reasons is that Monel Alloy 400 Square Nuts offer excellent corrosion resistance in both aqueous and high temperature applications.
Monel 400 Bolt/Nut Manufacturers, Monel 400 Bolt/Nut Suppliers, Monel 400 Bolt/Nut Stockists, Monel 400 Bolt/Nut Exporters
Monel 400 Bolt/Nut Manufacturers in India, Monel 400 Bolt/Nut Suppliers in India, Monel 400 Bolt/Nut Stockists in India, Monel 400 Bolt/Nut Exporters in India
Monel Alloy 400 Eye Bolts are often required in complex applications, where corrosion and thermal resistance are demanded. Monel Alloy 400 Eye Nuts are used in Petro – Chemical Industry, Oil and Gas Industry, Nuclear Industry, Pulp & Paper Industry, Research & Development, Mega Projects & Defense & Development Industries.
Monel 400 Bolt/Nut Manufacturers in Mumbai, Monel 400 Bolt/Nut Suppliers in Mumbai, Monel 400 Bolt/Nut Stockists in Mumbai, Monel 400 Bolt/Nut Exporters in Mumbai
In fact wing to the special grade of Monel Alloy 400 T-Bolts are used for all critical applications. Monel Alloy 400 T-Nuts is a nickel – copper alloy (about 67 % Ni – 23 % Cu) that is resistant to sea water and steam at high temperatures as well as to salt and caustic solutions. Monel Alloy 400 U-Bolts exhibits characteristics like good corrosion resistance, good weldability and high strength.
Is Nickel 400 the same as Monel 400?
Monel 400 (UNS N04400) is a nickel-copper alloy also known as Nickel 400 with exceptional corrosion resistance in a variety of situations. It possesses great strength and toughness across a wide temperature range and is resistant to chloride stress corrosion cracking.
What is a Monel Bolt?
Monel 400 Bolts are a nickel-copper alloy bolt that is corrosion resistant in a variety of situations. Monel 400 Bolt is one of the few alloy bolts that retains its strength in subzero temperatures, it is employed in severe conditions.
Alloy 400 Bolt/Nut Specifications
| Specifications | ASTM F 467 ASME SF 467 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Length | 3 mm to 200 mm |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Type | Hex Head Bolts, Square Bolts, U bolts, Eye bolts, T bolt, Hex Bolt, Lag Bolts, Counter sunk Bolts, Hex Head nuts, Square nuts, Lock nuts, Eye nuts, wing nuts, T nuts, Panel Nuts, Coupling Nuts, Dome nuts, Acorn Nuts. |
400 Monel Alloy Bolt/Nut Chemical Composition
| Monel 400 | Ni | C | Al | Mn | Si | Fe | Cu | S | Co | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max | – | – |
Monel Alloy 400 Bolt/Nut Mechanical Properties
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
Equivalent Grades for 400 Monel Bolt/Nut
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Hex Cap Screw Dimensions
| Table B4 HEX CAP SCREW DIMENSIONS | |||||||
|---|---|---|---|---|---|---|---|
| Bolt Size | A | B | C (min) | D | F Thread Length for Screw Lengths | ||
| max | min | 6″ and shorter | over 6″ | ||||
| 1/4″ | 0.2500 | 0.2450 | 7/16 | 0.488 | 5/32 | 0.750 | 1.000 |
| 5/16″ | 0.3125 | 0.3065 | 1/2 | 0.557 | 13/64 | 0.875 | 1.125 |
| 3/8″ | 0.3750 | 0.3690 | 9/16 | 0.628 | 15/64 | 1.000 | 1.250 |
| 7/16″ | 0.4375 | 0.4305 | 5/8 | 0.698 | 9/32 | 1.125 | 1.375 |
| 1/2″ | 0.5000 | 0.4930 | 3/4 | 0.840 | 5/16 | 1.250 | 1.500 |
| 9/16″ | 0.5625 | 0.5545 | 13/16 | 0.910 | 23/64 | 1.375 | 1.625 |
| 5/8″ | 0.6250 | 0.6170 | 15/16 | 1.051 | 25/64 | 1.500 | 1.750 |
| 3/4″ | 0.7500 | 0.7410 | 1-1/8 | 1.254 | 15/32 | 1.750 | 2.000 |
| 7/8″ | 0.8750 | 0.8660 | 1-5/16 | 1.465 | 35/64 | 2.000 | 2.250 |
| 1″ | 1.0000 | 0.9900 | 1-1/2 | 1.675 | 39/64 | 2.250 | 2.500 |
| 1-1/8″ | 1.1250 | 1.1140 | 1-11/16 | 1.859 | 11/16 | 2.500 | 2.750 |
| 1-1/4″ | 1.2500 | 1.2390 | 1-7/8 | 2.066 | 25/32 | 2.750 | 3.000 |
| 1-3/8″ | 1.3750 | 1.3630 | 2-1/16 | 2.273 | 27/32 | 3.000 | 3.250 |
| 1-1/2″ | 1.5000 | 1.4880 | 2-1/4 | 2.480 | 1-5/16 | 3.250 | 3.500 |
| 1-3/4″ | 1.7500 | 1.7380 | 2-5/8 | 2.893 | 1-3/32 | 3.750 | 4.000 |
| 2″ | 2.0000 | 1.9880 | 3 | 3.306 | 1-7/32 | 4.250 | 4.500 |
| 2-1/4″ | 2.2500 | 2.2380 | 3-3/8 | 3.719 | 1-3/8 | 4.750 | 5.000 |
| 2-1/2″ | 2.5000 | 2.4880 | 3-3/4 | 4.133 | 1-17/32 | 5.250 | 5.500 |
| 2-3/4″ | 2.7500 | 2.7380 | 4-1/8 | 4.546 | 1-11/16 | 5.750 | 6.000 |
| 3″ | 3.0000 | 2.9880 | 4-1/2 | 4.959 | 1-7/8 | 6.250 | 6.500 |
